Product Item : DLC-010
Category： Lamella Separator
Material: PP (Polypropylene) / Stainless Steel
Certification:CE Certificate
Function:High TSS removal
Applications: Industrial & Municipal Water Treatment
INQUIRY EMAIL

Horizontal Plate Clarifiers Description

The horizontal plate clarifiers in wastewater treatment is widely recognized due to their numerous advantages, such as their ability to handle high flow rates and their versatility across various industries. They are an essential element in the treatment process, appearing in sectors like municipal sewage treatment, industrial effluent processing, and water recycling. Proper installation and maintenance of lamella clarifiers are crucial for their optimal performance and compliance with environmental regulations. Recent technological advancements have further improved the efficacy of these systems, making them more sustainable and cost-effective solutions for wastewater management.

Horizontal Plate Clarifiers Functions

This is a water treatment equipment used to clarify water by separating suspended particles. Industries and wastewater treatment plants frequently use lamella clarifiers to improve the quality of treated water.

The lamella clarifier consists of 3 mm thick anti-clogging plates to facilitate water flow. Suspended particles are retained on the surface of the plates and accumulate as water circulates.

Its operation is based on the difference in density between suspended particles and water. Centrifugal pressure pushes lighter particles towards the surface, while heavier ones remain in suspension.

When suspended particles gather around the surface of the blades, a quick-drain system evacuates them.

Lamella Gravity Settler

Horizontal Plate Clarifiers Model

DLC-I Gravity Lamella ,V shape mud bucket, simple structure, no energy consumption.

DLC-II Lamella with scraper,Increase the mechanical transmission mechanism, the mud discharge is better and smoother, and it matches the unit with large processing capacity.

DLC-III Super hydraulic Lamella,Reduced footprint, efficient sedimentation, detachable transportation.

lamella separator

DLC Model	Capacities (m³/h)	Piping Connections()				Physical Dimensions(m)
DLC Model	Capacities (m³/h)	Inlet(a)	Effluent(b)	Sludge(c)	Backwash(d)	L	W	H
DLC-	5	80	80	50	50	2.55	1.6	2.9
DLC-	10	100	100	50	50	3.35	1.82	3
DLC-	15	100	100	50	50	3.35	2.02	3
DLC-	20	100	100	50	50	3.35	2.02	3
DLC-	30	150	150	50	50	4.2	2.22	3
DLC-	40	150	150	50	50	4	2.8	3
DLC-	50	200	200	50	50	4.65	2.82	3
DLC-	60	200	200	50	50	4.7	3	3
DLC-	70	250	200	50	50	6.4	2.6	3
DLC-	80	250	200	50	50	6.8	2.82	3
DLC-	100	250	250	50	50	7.05	3.02	3
