The DAGYEE system is automated by the control panel connected to the ultrasonic level detector located above the dosing solution compartment. As soon as the solution in the dosing compartment reaches “low level”, the detector activates the opening of the water feed electrovalve and the start-up of the dry feeder. The water meter controls the flow continuously. As soon as the “high level” is reached, the process cycle stops, although the mixers (one, two or three according the model) continue to operate.
The preparation solution enters the storage tank from the preparation tank through the aging tank. When the liquid level in the storage tank is at a high level, the preparation process stops automatically, and when the solution drops to a low level, the batching process starts automatically. Both the preparation tank and the curing tank are equipped with agitators to fully ensure the dilution and curing of the medicine. The preparation flow and concentration can be determined by adjusting the water inlet flow and adjusting the speed of the screw shaft.
Polymer preparation unit model
| Model | Capacity L/H | Volume L | Timing H | Dimensions MM | Weight KG | Power KW |
|---|---|---|---|---|---|---|
| DT300 | 300 | 450 | 0.6-1 | 1500*1000*500 | 300 | 1.8 |
| DT500 | 500 | 750 | 0.6-1 | 1500*1000*650 | 420 | 1.8 |
| DT1000 | 1000 | 1500 | 0.6-1 | 2000*1000*900 | 500 | 2.8 |
| DT1500 | 1500 | 2250 | 0.6-1 | 2000*1200*900 | 620 | 3 |
| DT2000 | 2000 | 3000 | 0.6-1 | 2500*1200*1000 | 800 | 3.9 |
| DT3000 | 3000 | 4500 | 0.6-1 | 3000*1500*1000 | 950 | 5.3 |
| DT5000 | 5000 | 7500 | 0.6-1 | 5000*1500*1000 | 1250 | 7 |
| DT10000 | 10000 | 15000 | 0.6-1 | 4800*1800*2000 | 3600 | 7 |
Considerable savings in terms of polymer usage and running costs
Precision in the preparation and batching stages, optimising the processes
Mixing properties adapted to specific needs of the process
Space saving and system centralisation
Well controlled hydraulic retention and contact times
An automatic water supply system comprising a shut-off valve, filter, safety pressure switch, pressure gauge, pressure reducer valve, solenoid valve, water meter with pulses, control valve, flow meter (with flow switch for minimum level flow rate) and special dispensing nozzle (for units that work with powder polymers).
Tanks made entirely in PPH, with inspection covers and emptying valves for each chamber.
Customized mixers, optimized to ensure a homogeneous mixture, are made of stainless steel.
Batching screw made entirely of stainless steel, with batching adjustment managed using a precise speed regulator.
Polymer preparation unit application
Using polymers and flocculants considerably facilitates the processes of removing particles and solids suspended in liquid in the fo lowing applications:
• Treating potable and industrial processing water
• Purifying waste water
• Treating sludge, in order to improve the performance of centrifuges and filter presses
• Processes for the paper, chemical, petrochemical, mineral processing, canning industries
