Energy-Efficient Polymer Mixing Unit for Sustainable Water Treatment Operations

Energy-Efficient Polymer Mixing Unit for Sustainable Water Treatment Operations

Product Item : DPT-1000
Category： PAM Polymer Preparation unit
Capacity:300-10000L
Motor: SEW/NORD/Customize
Electrical component: Schneider/Omron/Customize
Certification: SGS/CE/ISO 9001
INQUIRY EMAIL

polymer preparation unit description

Polymer preparation system is a relatively common flocculant preparation device. It is a complete set of equipment with dosing, stirring, liquid conveying, automatic control and integration. It is widely used in raw water in power plants, high-pressure feed water in boilers, and ground collection in oil fields. Dewatering and dewatering treatment systems, various petrochemical systems and wastewater treatment systems. Such as adding coagulant, phosphate, ammonia liquid, lime water, water quality stabilizer (corrosion inhibitor), scale inhibitor, liquid biocide, etc.

Polymer preparation unit principle

A continuous polymer solution preparation system using polyacrylamide powder, designed by Enviroflex, featuring a three-chamber stainless steel tank with three agitators. Available in 7 models with output capacities ranging from 500 to 7500 liters per hour, and adjustable solution concentrations from 0.05% to 0.4%.
The unit is fully automatic and equipped with an automated flow and concentration control system.

Polymer preparation unit model

<span style="font-family:Verdana;">设备规格表</span>

Model	Capacity L/H	Volume L	Timing H	Dimensions MM	Weight KG	Power KW
DT300	300	450	0.6-1	15001000500	300	1.8
DT500	500	750	0.6-1	15001000650	420	1.8
DT1000	1000	1500	0.6-1	20001000900	500	2.8
DT1500	1500	2250	0.6-1	20001200900	620	3
DT2000	2000	3000	0.6-1	250012001000	800	3.9
DT3000	3000	4500	0.6-1	300015001000	950	5.3
DT5000	5000	7500	0.6-1	500015001000	1250	7
DT10000	10000	15000	0.6-1	480018002000	3600	7

Polymer preparation unit advantage

Considerable savings in terms of polymer usage and running costs
Precision in the preparation and batching stages, optimising the processes
Mixing properties adapted to specific needs of the process
Space saving and system centralisation
Well controlled hydraulic retention and contact times

Polymer preparation unit feature

Each chamber is fitted with a tightly-secured inspection cover and emptying valve
User-guided input of solvent concentration
Minimal product carry over
Programmable logic controller (PLC)
Control cabinet for automatic control of the entire system
Optional automatic control panel version with proportional polymer dosage
Version with terminal box available on request

Polymer preparation unit application

Sludge treatment conditioning and dehydration
Wastewater treatment plants
Municipal purification plants
Industrial purification plants
Agri-food industries
Beverage industries
Livestock farms
Meat processing
Fish processing
Paper industries
Textile industries
