Lamella Plate Clarifier Description
A lamella plate clarifiera is type of settler designed to remove particulates from liquids.
They often employed in primary water treatment in place of conventional settling tanks. used in industrial water treatment. inclined plates provide a large effective settling area for a small footprint. The inlet stream is stilled upon entry into the clarifier. Solid particles begin to settle on the plates and begin to accumulate in collection hoppers at the bottom of the clarifier unit. Sludge drawn off at the bottom of the hoppers and the clarified liquid exits the unit at the top over weir.
Available options
Lamella Plate Clarifier Model
DLC-I Gravity Lamella ,V shape mud bucket, simple structure, no energy consumption.
DLC-II Lamella with scraper,Increase the mechanical transmission mechanism, the mud discharge is better and smoother, and it matches the unit with large processing capacity.
DLC-III Super hydraulic Lamella,Reduced footprint, efficient sedimentation, detachable transportation.
DLC
Model
Capacities
(m3/h)
Piping Connections()
Physical Dimensions(m)
Inlet(a)
Effluent(b)
Sludge(c)
Backwash(d)
L
W
H
DLC-
5
80
80
50
50
2.55
1.6
2.9
DLC-
10
100
100
50
50
3.35
1.82
3
DLC-
15
100
100
50
50
3.35
2.02
3
DLC-
20
100
100
50
50
3.35
2.02
3
DLC-
30
150
150
50
50
4.2
2.22
3
DLC-
40
150
150
50
50
4
2.8
3
DLC-
50
200
200
50
50
4.65
2.82
3
DLC-
60
200
200
50
50
4.7
3
3
DLC-
70
250
200
50
50
6.4
2.6
3
DLC-
80
250
200
50
50
6.8
2.82
3
DLC-
100
250
250
50
50
7.05
3.02
3
Lamella Plate Clarifier Advantages
To understand the popularity of Lamella Plate Clarifiers, let’s take a closer look at their benefits:
Space Saving: Up to 80% smaller than traditional clarifiers
Low Maintenance: Fewer moving parts, easy to clean
High Efficiency: Faster and better solids removal due to inclined design
Retrofit-Friendly: Perfect for upgrading older treatment systems
Cost Reduction: Lower operational costs via reduced energy and chemical use
Clearly, these advantages position lamella plate clarifiers as one of the most effective tools in modern water treatment.
Lamella Separator Applications
Lamella plate clarifiers are extensively used in the wastewater treatment process due to their efficiency in separating solids from liquids. These systems are particularly beneficial where the footprint area is limited as they provide a large settling area in a compact space. Below is a list of common applications:
