Lamella Separator Description
Lamella clarifiers are an integral component in the realm of wastewater treatment, providing a significant function in the clarification process by separating solids from liquids. They operate on the principle of sedimentation, where the gravitational force compels particles to settle at the bottom due to their higher density compared to water. The unique design of lamella clarifiers, characterized by inclined plates, maximizes the effective settling area within a compact footprint. This design accelerates the settling process, allowing for efficient solid-liquid separation.
Function
The Lamella clarifier works when a solid/liquid stream that has been flocculated, enters a tank, and flows upward between a pack of inclined plates. The solids fall to the plate surface, where they slide by gravity down to a sludge collection hopper. The clarified effluent flows through orifice holes and exits the top of the settler.
Lamella Separator Model
DLC-I Gravity Lamella ,V shape mud bucket, simple structure, no energy consumption.
DLC-II Lamella with scraper,Increase the mechanical transmission mechanism, the mud discharge is better and smoother, and it matches the unit with large processing capacity.
DLC-III Super hydraulic Lamella,Reduced footprint, efficient sedimentation, detachable transportation.
DLC
Model
Capacities
(m3/h)
Piping Connections()
Physical Dimensions(m)
Inlet(a)
Effluent(b)
Sludge(c)
Backwash(d)
L
W
H
DLC-
5
80
80
50
50
2.55
1.6
2.9
DLC-
10
100
100
50
50
3.35
1.82
3
DLC-
15
100
100
50
50
3.35
2.02
3
DLC-
20
100
100
50
50
3.35
2.02
3
DLC-
30
150
150
50
50
4.2
2.22
3
DLC-
40
150
150
50
50
4
2.8
3
DLC-
50
200
200
50
50
4.65
2.82
3
DLC-
60
200
200
50
50
4.7
3
3
DLC-
70
250
200
50
50
6.4
2.6
3
DLC-
80
250
200
50
50
6.8
2.82
3
DLC-
100
250
250
50
50
7.05
3.02
3
Lamella Separator Characteristics
Monroe Inclined Plate Vertical Clarifiers are carefully engineered to meet the specific requirements of each application. Well proven design criteria assure maximum performance of each clarifier. The design provides for easy field installation, fast start-up, and low maintenance costs.
While many installations provide adequate solids removal without influent pre-treatment, optional mixers and flocculator tanks are available to enhance efficiency when required. Some solids must be flocculated to achieve adequate mass to be effectively removed. Monroe Parallel Plate Vertical Clarifiers are manufactured in two different plate inclinations; the 45° clarifiers are designed for removal of heavy solids while the 55° clarifiers are designed for light solid removal applications.
Lamella Separator Applications
Water following physical-chemical treatment.
Tailings in mining and metallurgical beneficiation.
Solutions from gold leaching processes.
Wet scrubbing effluents.
Effluent treatment in pulp and paper mills.
Filter backwash.
