Corrosion-Resistant SS316L Screw Sludge Dewatering Equipment

Corrosion-Resistant SS316L Screw Sludge Dewatering Equipment

Product Item : DL-301
Category： Sludge Dehydrator
Material: SS304/SS316L
Productivity: 30-50KG/H
Machinery Test Report: Provided
Certification: CE /ISO9001
INQUIRY EMAIL

Sludge dehydrator descriptions

DAGYEE machines for sludge dewatering: Reliable and efficient methods of sewage sludge dewatering by means of screw presses and belt filter presses.

Sludge produced in municipal and industrial wastewater treatment plants requires dewatering prior to further treatment or utilisation. In view of increasing sludge disposal costs it has become necessary to concentrate the sludge to a high solids content.

DAGYEE offers for this purpose commonly known systems for continuous sludge dewatering, e.g. belt filter presses and screw presses.

Sludge dehydrator process

A screw press (SP) provides sludge dewatering by conveying the sludge along the inside of a permeable cylinder. It is based on a slowly-rotating (~5 RPM) Archimedean screw within a cylindrical screen (otherwise termed drum filter/screen or basket). It is normally inclined by ~20° to the horizontal to assist with the draining of water into the sump. The screen generally has an aperture rating below 0.5 mm and is based on wedge-wire or occasionally perforated metal.

The screens are less susceptible to clogging than the filter media used for other thickening and dewatering processes. Consequently, spray-cleaning is applied only intermittently for around 2−4% of the operating time.

As with all thickening and dewatering processes, the product solids (or cake) content is dependent on the feedwater sludge quality. The cake solids content has been shown to be inversely proportional to the volatile solids (VS) of the feed sludge.

Sludge dehydrator model

Model	DS capacity(g/h)		Sludge capacity (m³/h)		Sludge treatment capacity						Spiral diameter	Discharge Distance	Size(mm)			Net.Kg	Run Kg	Power	Washing Q
Model	Min	Max	2g/L	5g/L	2g/L	5g/L	10g/L	20g/L	25g/L	50g/L	Spiral diameter	Discharge Distance	L	W	H	Net.Kg	Run Kg	Power	Washing Q
DL101	3	5	1.5	0.6	1.5	0.6	0.5	0.25	0.2	0.1	Φ100×1	215	1816	756	1040	200	290	0.2	24
DL131	6	10	3	1.2	3	1.2	1	0.8	0.4	0.2	Φ130×1	260	1969	756	1040	220	315	0.36	24
DL132	12	20	6	2.4	6	2.4	2	1	0.8	0.4	Φ130×2	250	2069	910	1040	275	450	0.62	48
DL202	18	30	9	3.6	9	3.6	3	1.5	1.2	0.6	Φ200×2	350	2500	935	1270	470	730	1.11	64
DL301	30	50	15	6	15	6	5	2.5	2	1	Φ310×1	495	3255	905	1600	850	1320	0.74	40
DL302	60	100	30	12	30	12	10	5	4	2	Φ310×2	495	3455	1285	1600	1500	2230	1.11	80
DL303	90	150	45	18	45	18	15	7.5	6	3	Φ310×2	495	3055	1690	1600	1520	3080	1.86	120
DL352	120	200	60	24	60	24	20	10	8	4	Φ350×2	580	4240	1550	2190	1950	3400	3.75	144
DL353	180	300	60	36	60	36	30	15	12	6	Φ350×3	580	4460	2100	2160	2600	4850	6	216
DL402	120	200	60	24	60	24	20	10	8	4	Φ410×2	585	4140	1550	2250	2450	3400	3.75	144
DL403	180	300	60	36	60	36	30	15	12	6	Φ410×3	585	4420	2100	2250	3350	4850	6	216

Sludge dehydrator advantages

Efficient Dewatering

The machine employs a screw press mechanism that applies gradually increasing pressure and compression to the sludge. This results in effective water extraction, leading to high dewatering efficiency. It helps reduce the moisture content and the volume of sludge, resulting in lower transportation and disposal costs. Moreover, the machine can operate independently or multiple units work together.

Compact Design

The machine is designed with a compact structure, occupying small space so that it can easily work with existing wastewater treatment systems. Besides, the modular design makes it easy to install and maintain.

Continuous Operation

The machine operates continuously, allowing for a consistent and uninterrupted dewatering process for 24 hours. It can be automatic, with low maintenance and monitoring needed.

Low Energy Consumption

The slow rotation speed of the screw press, typically ranging from 1 to 4 RPM. It requires lower energy consumption compared to high-speed centrifuges or belt filter presses, which helps to reduce operation costs.

Great Durability

The entire machine is built with 304 stainless steel, including the movable and fixed plates, screw press, flocculation mixing tank, metering tank, control box, casing and frame. Especially, the screw press and blades are wear-resistant and heat-treated to prolong its service life. And the entire machine is under a one-year warranty.
