Durable Bag Filter Housings for High-Volume Filtration

Bag Filter Housings Description

Cartridge filter housings are critical components ensuring efficient and effective filtration. DAGYEE manufactures a broad line of both ASME code vertical and horizontal cartridge housings with standard flow rates of up to 8,000 GPM.  Housings are built to meet project specifications. DAGYEE is the custom manufacturer of cartridge filter housings for industrial filtration needs.

Bag Filter Housings Function

Inflow: The unfiltered liquid enters the common inlet chamber of the housing.

Parallel Distribution: The flow is evenly distributed across all the filter cartridges housed within the vessel.

Simultaneous Filtration: The fluid passes from the outside to the inside of each cartridge simultaneously. Contaminants are trapped on the exterior surface or within the depth of the cartridge media.

Consolidated Outflow: The purified fluid from each cartridge converges into a common outlet chamber before exiting the housing.

High Capacity: This parallel design allows the system to handle large volumes of fluid while capturing a significant amount of contaminants before maintenance is required.

Bag Filter Housings Parameter

Bag Filter Housings Advantage

• Single cartridge design
• Patented Up-flow design
• Coated option available
• Flow rates to 150 GPM (WB) and to 600 GPM (WB 5x170FL)
• Offered in 304 / 316 stainless steel

Bag Filter Housings Characteristics

High-Capacity Design: Constructed to hold several to dozens of cartridges, significantly increasing the total filtration surface area and dirt-holding capacity.

Robust Construction: Typically made from carbon steel with protective coatings or stainless steel (SUS304/316L) for strength and corrosion resistance in demanding environments.

Efficient Flow Distribution: Internal baffling or design features ensure even flow across all cartridges, preventing premature clogging of any single cartridge.

Top-Service Design: Features a large, removable top head or bolted cover for easy access to all cartridges simultaneously, simplifying maintenance.

Integrated Accessories: Often includes accessories like pressure gauges (inlet/outlet), vent valves, and drain valves for operational control and safety.

Scalability: Available in various sizes and cartridge counts (e.g., 3, 7, 12, 21-cartridge models) to match specific flow rate requirements.

Bag Filter Housings Application

Our housings are extensively used in the chemical, food and beverages and minerals & mining industries.
