Compact Single Cartridge Housing for Small-Scale Filtration

Cartridge Filter Housing Description

Cartridge filter housings are critical components ensuring efficient and effective filtration. DAGYEE manufactures a broad line of both ASME code vertical and horizontal cartridge housings with standard flow rates of up to 8,000 GPM.  Housings are built to meet project specifications. DAGYEE is the custom manufacturer of cartridge filter housings for industrial filtration needs.

Cartridge Filter Housing Structure

Housing Body

The housing body is the main structure that encloses the filter cartridges. It is typically made from materials such as stainless steel, carbon steel, or durable plastics to withstand high pressures and corrosive environments.

Filter Cartridges

The filter cartridges are the primary filtration elements, available in various materials such as pleated polypropylene, cellulose, or activated carbon. The choice of cartridge depends on the specific application and the type of contaminants to be removed.

Inlet and Outlet Ports

These ports allow fluid to enter and exit the housing. They are designed to accommodate various pipe sizes and connection types, ensuring compatibility with different systems.

Closure Mechanism

The closure mechanism secures the housing body and ensures a tight seal to prevent leaks. It can include clamps, bolts, or swing bolts, depending on the design.

Gaskets and Seals

Gaskets and seals are used to ensure a leak-proof connection between the housing body and the closure mechanism. They are typically made from materials such as silicone, EPDM, or Viton.

Pressure Gauges

Pressure gauges monitor the differential pressure across the filter cartridges, providing an indication of when the cartridges need to be replaced.
Vent and Drain Ports: Vent and drain ports are used to remove air and accumulated debris from the housing during maintenance and cartridge replacement.

Cartridge Filter Housing Parameter

Cartridge Filter Housing Advantage

• High quality materials
• Innovative design concepts
• Rugged heavy-duty construction
• Advanced engineering

Cartridge Filter Housing Characteristics

• Compact design
• Manufactured in stainless steel
• No internal moving parts to allow for easy access and reducing the cost of maintenance.
• Ergonomic and easy-to-use cover closure.
• Fully drainable filter housing.
• Suitable for filter cartridges of 10″, 20″, 30″ or 40″ length
• Available from stock. Amafilter® can supply four standard sizes in stainless steel from stock. These are available with flanged connections.

Cartridge Filter Housing Application

• Wastewater
• Water & liquid applications
• Corrosion – resistant materials make vessels suitable for hot water and high pressure applications as well as a range of industrial and commercial usages. Also compatible with high-purity water and fluids.
• Chemical fluid treatment
• Oil & Gas
